Raspberry Pi Zero W – s WiFi a BT

Raspberry Pi Zero W – Raspberry Pi Zero s 2.4GHz 802.11n wireless LAN a Bluetooth Classic 4.1 and Bluetooth LE.

Ostatní komponenty zůstavají z původní verze:

Dimensions: 65mm × 30mm × 5mm

SoC: Broadcom BCM2835

CPU: ARM11 running at 1GHz

RAM: 512MB

Wireless: 2.4GHz 802.11n wireless LAN

Bluetooth: Bluetooth Classic 4.1 and Bluetooth LE

Power: 5V, supplied via micro USB connector

Video & Audio: 1080P HD video & stereo audio via mini-HDMI connector

Storage: MicroSD card

Output: Micro USB

GPIO: 40-pin GPIO, unpopulated

Pins: Run mode, unpopulated; RCA composite, unpopulated

Camera Serial Interface (CSI)

Cena začíná na £9.60 za samotný Raspberry Pi Zero W.

Informaci sdílel https://www.raspberrypi.org/magpi/pi-zero-w/

Na obrázku níže je vidět interní anténa

We spoke to Roger Thornton, principal hardware engineer, about the new antenna:

“The Raspberry Pi 3 antenna is a surface-mount component,” explains Roger, “whereas the Zero W antenna is a resonant cavity which is formed by etching away copper on each layer of the PCB structure.”

The technology is licensed from a Swedish company called Proant (you can see the credit on the reverse of the Zero W board).

“They’re very clever boffins,” says Roger. “It’s a really neat design.”

The triangle recession in the board is known as the ground plane. This free space is used to interact with the radio waves. They resonate in this cavity at just the right frequency. The two components at the small side, right up by the board, are a couple of capacitors which capture the radio signal.

Here’s a sweet, sweet diff image of the new Zero W and the previous Zero version.

https://twitter.com/pimoroni/status/836510914094510080/photo/1

Vývoj Raspberry Pi Zero

http://raspi.tv/2017/pi-zero-w-wifi-on-the-zero-for-10-and-a-gorgeous-new-case

K dispozici je i nová krabička

i s otvorem pro kameru

Video:
